Smart Airflow Unit

• Steel supporting pallet and covering structure • Automatic Wood Pellet Boiler with automatic cleaning and deashing
• Efficiency >90% • Output Modulation 30–100% • 400 l fuel bin • Electronically controlled Hot-Air fan unit with 0–270° movement • Complete chimney supply • Complete hydraulics supply • Special operation visualisation • Mobile phone control • Internet control

Smart Airflow Unit Delivery Description:

• Compact steel supporting pallet for easy handling & positioning
• Smart 30/50/80 kW Wood Pellet Boiler
• 250 kg fuel store including fuel auger
• 2 000 mm 3-layers chimney set
• Hot-Air fan unit with 0–270 degree movement range
• Circulation pump
• Drain valve
• Pressure control
• Expansion tank
• Pressure release valve
• Automatic control vent
• Heat meter – Optional

Special Operation Visualisation:

Smart 30/50/80 kW Wood Pellet Boiler Features:

• Steel construction with heavy duty coaxite coating for long life
• Multiple fuelling options: auger, vacuum or manually fed
• Advanced Control Unit for automatic operation
• High efficiency – over 90%
• Output Modulation from 30–100% depending on actual heat demand
• Cast Iron burner construction with exchangeable burner surface
• Automatic electrical ignition
• Self-cleaning, vertical turbulator heat exchanger
• Safety thermostat with automatic cut-off
• Automatic de-ashing c/w wheelie ash bin
• Remote Monitoring via Internet or GSM
• Integral flue fan – Optional

Installation Space Requirements:


Airflow Unit Dimensions		Airflow Unit Weight
1 900 x 1 130 x 2 885 mm		815 kg / 920 kg

Thermal and technical parametres	Unit	AirFlow 30 kW	AirFlow 50 kW
Rated output	kW	29	49,5
Output range	kW	8,6 – 29	14,6 – 49,5
Fuel consumption	kg x hrs-1	1,9 – 6,6	3,44 – 11,63
Effecienty (rated output)	%	90,9	90,4
Flue Gas temperature rated output	°C	94 – 148	110 – 153
Class of the boiler		5	5
Burning time min/rated output (based on fuel storage of 250 kg)	hours	147 – 42	80 – 24
Technical parameters of products
Weight	kg	815	920
Water content	litres	140	190
Flue duct diameter	mm	150	160
Dimension (widthxdept) excluding ash box	mm	1130 x 1900	1130 x 1900
Maximum water presure	bar	up to 3	up to 3
Required fl ue draught	mbar	0,1 – 0,2	0,1 – 0,3
Recommenteded operating temperature of heating water	°C	60 – 80	60 – 80
Lowest temperature of incoming water	°C	55	55
Sound power level	dB	57	57
Output power 70/50 °C, 10 °C	kW	32,48	53,91
Air circulation range in open space	m	22,5	17,5
Middle level of sound pressure	dB	64,5	67,2
Electrical parametres of products
Connection voltage		230 VAC ±10%, 50 Hz ± 2 Hz	230 VAC ±10%, 50 Hz ± 2 Hz
Maximum electrical input – ignition	V	1200	1200
Electrical protection of the control unit		IP54	IP54
Electrical protection of the boiler wiring		IP20	IP20
Fuel and it s parametres
Wood pellets diameter	mm	6,0 – 8,5	6,0 – 8,5
Calorific value	MJ/kg	approximately 16 – 18	approximately 16 – 18
Water content		Up to 10%	Up to 10%
Ash content		Up to 1% (0,8 – 1,0%)	Up to 1% (0,8 – 1,0%)
